Optional Equipment. Auto lube installation for automatic greasing of bearings. Body liners. CD/Radio, heavy duty with auxiliary input. Cold weather coolant -51° C (-60° F). Cold weather start attachment.
Engine block heater. Ether Start. Exhaust heated body. Fast fuel fill.
Flashing LED beacon. Fuel additive-anti-waxing. Heated seat. Heated rearview motorized mirrors.
Machine Security System (MSS). Product Link PL 321, PL 523 (where available).
Roof mounted, HID, work lights. Tailgate.
Scissor-type. Tires, six 750/65. Windshield wiper and washer, two speed (rear). Cat Clean Emissions Module (CEM) The Cat CEM is an exhaust aftertreatment package consisting of a Diesel Particulate Filter (DPF), Selective Catalytic Reduction (SCR)catalyst, using a urea water solution (UWS), known as Diesel Exhaust Fluid (DEF), and control systems.
The CEM reduces both particulate and NOx emission using passive and active regeneration, dosing, burner and dosing/burner combinations during normal engine operation. All components are isolation mounted on a rigid supporting cradle for long service life in the most severe applications.
Modes of Regeneration When set to automatic, regeneration will occur without any interaction from the operator. The three modes of regeneration shown below allow the articulated truck to adapt to specific site conditions in the most efficient manner. Automatic: “On-the-go” regeneration is initiated when the engine control module determines conditions are acceptable. The articulated truck is not required to stop working.
Automatic: Low idle regeneration is initiated when the machine is in a reduced operating mode for a predetermined period of time, and a number of conditions are met. The system is designed so that the operator can interrupt regeneration at any time.
Caterpillar Equipment Repair Manuals
Manual: A manual regeneration is initiated by pressing the regeneration switch for five seconds. The machine must be brought to a non-operating mode in order to perform a manual regeneration. Electronic Transmission The Cat CX31 six-speed forward one-speed reverse Electronic Clutch Pressure Controlled (ECPC) transmission featuring Advanced Productivity Electronics Control Strategy (APECS) delivers smooth shifting with strong acceleration and high productivity. The Cat C13 ACERT engine coupled with the CX31 transmission deliver increased forward and reverses rimpull. Featuring:. A speed hold/limiting function allows the machine speed to be limited in one km/h or one mph steps to conform to site speed restrictions.
Critical gearshifts maintain direct drive lock-up, and eliminate dropping into converter drive. This maintains ground speed during shifts on grades. The transmission automatically modifies shift points to best suit operating conditions. Retarding levels are automatically reduced on lesser grades in lower gears.
Automatic Traction Control (ATC) Fully Automatic Traction Control (ATC), with Inter-Axle-Differential lock (IAD) and Cross-Axle-Differential locks (XAD) feature oil immersed clutches that require no operator input. Operation is seamless and smooth, eliminating wheel slip for maximum traction. Sensors monitor the machine and wheel speeds, enabling instant response in low traction conditions.
Fully automatic, independent, IAD and XAD clutches are engaged on-the-go to optimize machine performance and control in all conditions. Clutches are automatically disengaged when ground conditions dictate, maximizing efficiency when steering or on uneven ground. Clutches are engaged proportionally, from 0% to 100%, as ground conditions dictate. ATC eliminates wheel spin in soft underfoot ground conditions or on slippery grades.
It also reduces tire and driveline abuse caused by improper manual operation of the differential clutches. The ATC allows ‘true’ 6×6 drive with proportionally open differentials for best power efficiency. Dash The integrated wrap-around dash puts all controls within easy reach of the operator. Featuring LED illuminated rocker switches for the dash dimmer, rear wash wiper, hazard warning, head lamp, work lamp, heated mirrors (optional), secondary steer, heated seat (optional), machine security system (optional), A/C and cigar lighter. The Color Multi-Purpose Display (CMPD) unit incorporates the messenger and rear camera display.
The cab provides an automotive feel with the industrial strength you would expect from Caterpillar. Cat Product Link. Cat Product Link allows remote monitoring of the Articulated Truck to improve overall fleet-management effectiveness. Product Link is deeply integrated into machine systems. Events and diagnostic codes, as well as hours, fuel, idle time and other detailed information are transmitted to a secure web based application, VisionLink®. VisionLink includes powerful tools to convey information to users and dealers, including mapping, working/idle time, fuel level and more.Product Link licensing not available in all areas. Please consult your Cat dealer for availability.
Key Points. See your entire fleet at a glance. Monitor fuel usage. Set up site boundaries and security alerts.
Click through to your Cat dealer for service and parts. Customize the alerts and displays that matter to you. Compare working time versus idle time. Reduce owning and operating costs.
Get the right information to the right people at the right time. Vital Information Maintenance System (VIMS™) upgrades available.
Robust new hardware. Remarkably intuitive web-based interface. Satellite and cellular coverage. Open-system design for mixed-fleet use. Safety Features.
Cab integral ROPS (Roll Over Protection System) and FOPS (Falling Object Protection System). Rearview camera system provides a continuous panoramic rearview or when reverse gear is selected. The secondary and parking brake functions are spring applied and hydraulic released. Electro-hydraulic secondary steering system automatically activates in forward/reverse or when stationary if low pressure is sensed. Can be manually selected for machine recovery purposes.
