Service Manual 3024c Engine
) Cylinder arrangement. In-line Type of combustion. Indirect injection Compression ratio. 23.3:1 Number of cylinders. 4 Valves per cylinder.
2 Valve lash Inlet valve. 0.2 mm (0.0078 inch) Exhaust valve. 0.2 mm (0.0078 inch) Firing order. 1, 3, 4, 2 When the crankshaft is viewed from t he front of the engine, the crankshaft rotates in the following direction.
Clockwise When the camshaft is viewed from the front of the engine, the camshaft rotates in the following direction. Instal l Too ling (A) o n the nose of th e cran kshaft.
Align p in (2) with h ole (X) in oi l pump co ver (10 ). Ensure th at the oil pu mp cover is concentric to idler gear assembly (11). Ins tall a ne w jo int to p lat e (5 ). Guide th e linkag e for the fu el inject ion pum p into po sition so th at the link i s free to move inside the aperture on the cylinder block for the fuel injection pump.
Align front housing (6) to the dowels in plate (5). Install front housing (6) to plate (5).
Instal l fasten ers (3) and tig hten to a t orqu e of 10 N m (89 lb in). Remov e Tool ing (A ) fro m the n ose of the cr anksh aft.
Instal l a new O-rin g seal (7) to fr ont hou sing (6 ). Positio n cover (8 ) on fro nt housing (6) and install nuts (4) a nd bolts (9).
Tigh ten nut s (4) to a to rque o f 50 N m (37 lb ft). If the engine is eq uipped with a turbocharg er, connect the hose to connection (1).
Preview Description Factory Repair Manual For Caterpillar 247B 257B Multi Terrain Loader Powered By 3024C Engine. Step by step instructions, illustrations, diagrams: Testing and Adjusting, Disassembly and Assembly, Remove and Install, Specifications, Operations, Schematics and much more for machine repair. = Printable = Zoom able = Clickable index = Bookmarks = Searchable Text MODELS Multi Terrain Loader Caterpillar 247B MTL4 Caterpillar 257B SLK9 3024C Engine SECTIONS. Air Inlet And Exhaust System. Basic Engine. Cooling System.
Cat 3024c Engine Problems
Electrical And Starting System. Engine Arrangement. Frame And Body.
Fuel System. Hydraulic System. Implements.
Lubrication System. Machine Arrangement. Operator Station. Powertrain. Service Equipment And Supplies.
Work Tools. Torque Specification. Schematic – Electrical System. Schematic – Hydraulics System.
